Muaj nuj nqi thiab Kev Taw Qhia
Tsis siv neeg trimming ntawm kab
1.Short ntug ntawm lub module nkag thiab tawm.
2. Tsis siv neeg txiav rau cov khoom siv ntau dhau ntawm cov khoom siv tom qab lamination.
3.Kev hloov kho sai rau ntug ntev, luv ntug thiab nqus disc. Nws ceev thiab yooj yim rau kev hloov qauv.
4.Circulation txiav tau nqa mus rau plaub ntug nrog high efficiency.
5.Txiav riam muaj kev sib cuag nrog iav, tiv tauj xovxwm tuaj yeem ua tiav qhov kev hloov kho yooj yim.
6.Lub tshuab muaj cov khoom sib sau lub thawv rau kev txiav cov khoom thiab cov qauv tsim ua kom yooj yim rau kev ntxuav.
Main parameter
Muaj feem xyuam module hom:(1580-2000)mm*(800-1000)mm ,
Lub sijhawm voj voog:<30s ,
Max peev xwm: ≥2880pcs / hnub,
Cov neeg ua haujlwm xav tau ntawm kab: tsis muaj
Rated zog (kw): 2.06kw,
Siab (MPa): 0.6MPa ,
Qhov loj me (L × W × H): 2850mmx1950mmx1110mm.
Qhov zoo
1.Cov cuab yeej ua los ntawm steel, compressive zog siab dua, ruaj thiab txhim khu kev qha.
2.Lub tshuab yog tsav los ntawm servo lub cev muaj zog, hloov los ntawm chains thiab coj los ntawm linear rail, muaj qhov zoo xws li qhov tseeb qhov chaw thiab ruaj khov khiav.
3.Lub tshuab yog nruab nrog lub laj kab kev nyab xeeb rau kev tiv thaiv zoo.
4.Qhov plaub ntug ntawm lub module raug txiav tib lub sijhawm nrog kev ua haujlwm siab thiab ruaj khov.
5.Cov hniav siv arc txiav ntug thiab sab nraub qaum ntawm cov hniav tuaj yeem tshem tawm cov khoom seem ntawm lub module.
6.Cov hniav siv cov qauv hloov ceev uas tuaj yeem ua rau kev hloov pauv sai thiab yooj yim.
7. Cov hniav uas yuav tsum tau tsav los ntawm lub siab precision thaiv, tuaj yeem hloov kho los ntawm qhov chaw hnav mus rau qhov chaw tsis hnav. Qhov no tuaj yeem txo tus nqi thiab nce tus naj npawb ntawm cov hniav siv thiab kev ua haujlwm zoo
|
