PV Module Ntau Lawm Kab Nrog Customized Capacity

1. Cov khoom siv yog tsav los ntawm servo lub cev muaj zog, nrog lub iav thiab khib tsav thiab cov kab ntawv qhia kev tsheb nqaj hlau, uas muaj qhov zoo ntawm kev ua haujlwm raug thiab ua haujlwm zoo;
2. Lub tshuab tag nrho yog nruab nrog lub laj kab kev nyab xeeb, thiab muaj kev tiv thaiv kev nyab xeeb;
3. Cov ncej clip yog ruaj khov thiab txhim khu kev qha, thiab cov ncej tsis khawb;
4. Lub tshuab tag nrho yog nruab nrog lub hwj chim tawm thiab kev tiv thaiv roj;
5. Cov cuab yeej siv tau ua haujlwm, thiab cov txheej txheem ua haujlwm tsis tas yuav muaj kev cuam tshuam cov neeg ua haujlwm;
6. Lub lag luam thiab programming interface yog yooj yim thiab yooj yim rau siv

1. Cov khoom siv yog tsav los ntawm servo lub cev muaj zog, uas tau tsav los ntawm iav khib, thiab cov ntawv qhia kev tsheb ciav hlau, kev ua haujlwm raug thiab du;
2. Lub tshuab nqus tsev twj tso kua mis yog ua los ntawm cov khoom siv polyurethane, uas yuav tsis imprint lub khob hauv cov txheej txheem nqus;
3. Lub tshuab tag nrho yog nruab nrog lub laj kab kev nyab xeeb, thiab muaj kev tiv thaiv kev nyab xeeb;
4. Lub sab sauv thiab qis ntawm lub thawv ntim khoom yog yooj yim thiab yooj yim rau cov neeg ua haujlwm ua haujlwm; 5. Lub tshuab tag nrho yog nruab nrog lub hwj chim tawm thiab kev tiv thaiv roj;
6. Tsis siv neeg tswj cov khoom siv, tsis tas yuav muaj kev cuam tshuam cov neeg ua haujlwm thaum lub sijhawm ua haujlwm;
7. Lub lag luam thiab programming interface yog yooj yim thiab siv tau yooj yim;
8. Lub zeem muag txawj ntse coj tus tswj kom raug qhov chaw.

1. Daim ntawv ua haujlwm tsis siv neeg txo cov kua nplaum ua kua nplaum;
2. Qhov tseeb piv, cov kua nplaum sib xyaw ua ke, kom ua tiav qhov kev ua tiav tag nrho;
3. Sib tov kom zoo kom tsis txhob muaj cov khoom pov tseg los ntawm cov kua nplaum cuav;
4. Servo tsav, siab kua nplaum f仆ling raug;
5. Khoos phis tawj programming thiab tswj, nrog rau qib siab ntawm kev txawj ntse, yooj yim thiab yooj yim rau kev khiav lag luam.

1. Cov khoom siv yog tsav los ntawm servo lub cev muaj zog, uas muaj qhov zoo ntawm qhov tseeb thiab kev ua haujlwm du;
2. Lub tshuab tag nrho yog nruab nrog lub laj kab kev nyab xeeb, uas muaj kev tiv thaiv kev nyab xeeb;
3. Tsis siv neeg tswj cov khoom siv, thiab cov txheej txheem ua haujlwm tsis tas yuav muaj kev cuam tshuam cov neeg ua haujlwm;
4. Thaum ua haujlwm, plaub sab ntawm cov khoom raug txiav tib lub sijhawm, uas muaj qhov zoo ntawm kev ua haujlwm siab thiab stab 巾ty;
5. Teeb tsa cov cuab yeej coj los tiv thaiv cov khoom pov tseg ntawm kev txaws;
6. Cov hniav siv lub voj voog arc ntug, txiav kom huv si, thiab siv cov hniav rov qab ntug kom tshem tawm cov khoom seem ntawm cov khoom seem;
7. Yooj yim los hloov cov hniav

1. Lub sij hawm voj voog 17s, kev kub ceev
2. Strong compatib 巾ty: sib xws nrog Multi-shard ntawm 6 txoj hlua, 5 txoj hlua ib leeg Bypass soldering thiab 6 txoj hlua ob npaug Bypass soldering
3. Kho ob zaug rau txoj hauj lwm ntawm 10/12 series hallf piece cell string, grabs cell string by nqus adsorption, ib zaug khoob soldering thiab siab vuam raug.
4. Yooj yim specification conversion.
5. tuaj yeem xuas nrig ntaus ntawm qhov kawg ntawm lub tsheb npav ribbon
6. Ib sab pub, yooj yim rau kev khiav lag luam
7. Ob chav Bypass soldering kev koom ua ke tuaj yeem ua tau raws li cov neeg siv khoom xav tau rau 6 txoj hlua ob chav Bypass soldering ntawm bypass npav ribbon, tuaj yeem kaw lossis qhib raws li qhov xav tau siv tiag tiag.
8. Qhov tsawg tshaj plaws hauv pem teb cheeb tsam, qis tshaj CoO.

1. Lub tshuab siv lub tshuab synchronous siv, tsav los ntawm servo lub cev muaj zog, thiab coj los ntawm cov kab qhia kev tsheb ciav hlau, uas muaj qhov zoo ntawm qhov tseeb qhov chaw, kev ua haujlwm ruaj khov, thiab ceev ceev.
2. Lub khob nqus dej yog ua los ntawm polyurethane thiab yuav tsis muaj qhov cim tseg ntawm txoj hlua roj teeb tom qab nqus.
3. Lub tshuab yog nruab nrog lub zog thiab kev tiv thaiv roj.
4. Lub tshuab ua haujlwm tsis siv neeg thiab tsis tas yuav muaj kev cuam tshuam los ntawm phau ntawv.
5. Qhov tseeb qhov chaw ntawm cov hlua roj teeb yog ± 0.3 millimeters
6. Rau txoj hlua hluav taws xob nyob nruab nrab ntawm 1-10 millimeters sib nrug
7. Tau tshaj ntau txoj hlua roj teeb, loj 156/182/210, 6-12 daim
8. Lub ntsiab solar hlwb ntiv tes yog sib xws nrog 2/3/4/5 ntiv tes

Cov kab ntau lawm: Cov kab ntau lawm muaj peev xwm ntawm 50MW txog 500MW ib xyoos twg.

Cov Khoom Siv Hluav Taws Xob: Cov khoom siv ua haujlwm ntawm 380V fais fab mov siv peb-theem, tsib-xaim system. Lub zog tshwj xeeb xav tau rau txhua lub tsev tuaj yeem pom hauv lawv cov khoom siv tsis tau. Ib txoj kab hluav taws xob sib cais yuav muab los ntawm peb lub tuam txhab.

Compressed Air Requirements: Cov khoom yuav tsum tau compressed cua ntawm ib tug siab ntawm {{0}}.6-0.8MPa, uas yuav tsum tau qhuav, huv si, thiab ua tau raws li cov qauv rau automated ntau lawm kab. Cov huab cua yuav tsum muaj cov hmoov av suav tsawg dua lossis sib npaug li 1µm, qhov dej dew point Tsawg dua lossis sib npaug rau -40 degree , thiab roj (nrog rau vapor) qib Tsawg dua lossis sib npaug li 0.1mg / m³.

Huab cua huv hauv lub Hoobkas: Lub Hoobkas huab cua yuav tsum muaj kev huv huv tsis pub tsawg dua 300,000 (ISO Class 8).

Conveyor Ceev: Lub sijhawm xa khoom lub voj voog yuav tsum nyob rau hauv 22 vib nas this, uas tsim nyog los txhawb lub peev xwm ntawm 500MW ib xyoos twg. Lub kaw lus siv qhov sib txawv zaus tsav (VFD) tswj, nrog rau lub ntsiab zaus teem rau 30Hz, thiab adjustable ceev ntau yam ntawm 0-50Hz (tej ceev muaj peev xwm nrhiav tau nyob rau hauv cov khoom tsis txwv rau txhua chav tsev).

Sab nraud Dimensions ntawm Conveyor Line: Cov khoom siv tsis yog tus qauv, thiab daim duab kos duab kawg yuav muab los ntawm Edobo Solar.

Sib dhos Kab Qhov siab thiab qhov hloov kho: Tej zaum yuav muaj qhov sib txawv qhov siab ntawm ib tus neeg cov khoom siv thiab cov khoom siv conveyor. Rau qhov tshwj xeeb sab nraud, thov xa mus rau cov kev tsis sib xws ntawm tus kheej cov cuab yeej siv. Tus qauv siab ntawm chav tsev conveyor feem ntau yog 950mm ± 30mm.

Adjustable Range of Conveyor: Kev ua haujlwm ntau ntawm cov kab conveyor thiab cov khoom siv tuaj yeem hloov kho rau cov khoom siv nrog qhov ntev ntawm 1650mm thiab 2600mm thiab dav ntawm 950mm thiab 1500mm, txhawb ntau txoj kev lamination rau kev thauj khoom.

Conveyor Line Smoothness: Cov kab conveyor yuav tsum ua haujlwm zoo, nrog rau cov offsets tsis pub tshaj 10mm.

Component Failure Rate: Thaum cov cuab yeej ua haujlwm tau zoo, cov khoom siv tsis ua haujlwm raug ntaus nqi los ntawm cov khoom siv lossis cov kab conveyor yog tsawg dua 1 ntawm 1000.

Lub suab nrov: Cov suab nrov thaum lub sijhawm ua haujlwm ntawm cov khoom siv yuav tsum tsis pub tshaj 72dBA, tsis suav nrog cov suab nrov ntawm cov twj compression.

1. Lub xovtooj ntawm tes txais CCD pom qhov chaw, uas muaj qhov zoo ntawm qhov raug thiab ruaj khov;
2. Cov cuab yeej tuaj yeem tau txais, txiav layout thiab txiav cov khoom xa tawm, thiab cov txheej txheem yog qhov tseeb;
3. Lub khob nqus dej yog ua los ntawm cov khoom siv silicone uas tuaj yeem, uas yuav tsis tawm ntawm qhov chaw ntawm lub roj teeb;
4. Txais peb-axis mechanical motion mode (rotating 180 degree);
5. Lub lateral txav adopts linear motor module, uas muaj qhov zoo ntawm kev txav ceev ceev, siab rov ua dua qhov tseeb thiab kev ua haujlwm ruaj khov, txuag lub sijhawm tag nrho;
6. Ntev thiab luv ntug hloov pauv hloov kho sai sai, kev hloov kho sai, yooj yim, yooj yim thiab txhim khu kev qha;
