Hnub ci vaj huam sib luag rau tuam txhab
Hauj lwm lawm
Kev tsis
Qhia peb lub tuam txhab:
Yantai Edobo Tech.Co., Ltd yog lub tuam txhab suav tshwj xeeb hauv kev tsim khoom thiab muag khoom ntawm hnub ci zog khoom. Peb cov khoom muaj xws li hnub ci vaj huam sib luag, roj teeb, inverters, thiab ua tiav lub hnub ci zog. Peb lub hom phiaj yog los pab txhawb rau lub neej tom ntej kom huv thiab ruaj khov los ntawm kev tsim thiab muab cov kev daws teeb meem tshiab hnub ci zog.
Ntawm Yantai Edobo Tech.Co., Ltd, peb tau cog lus los xa cov khoom zoo tshaj plaws, kev ua tau zoo, thiab kev ntseeg siab. Tag nrho peb cov khoom raug tsim los siv cov cuab yeej siv siab tshaj plaws thiab tau txais kev sim nruj kom ntseeg tau tias ua raws li cov qauv thoob ntiaj teb. Peb pab neeg ntawm cov kws tshaj lij tau mob siab rau muab kev pabcuam tshwjxeeb rau cov neeg siv khoom thiab kev pabcuam kev pabcuam kom ntseeg tau tias muaj kev paub zoo tshaj plaws rau peb cov neeg siv khoom.
Feature ntawm cov khoom:
Peb lub hnub ci vaj huam sib luag rau cov tuam txhab yog qhov zoo tshaj plaws, kev daws teeb meem rau lub ntiaj teb kev xav tau ntawm lub zog. Nrog peb cov vaj huam sib luag, koj lub tsev lossis kev lag luam tuaj yeem siv lub zog ntawm lub hnub kom txo tau koj qhov kev cia siab ntawm cov khoom siv hluav taws xob ib txwm muaj thiab ua kom muaj qhov sib txawv tiag tiag hauv peb cov kev siv zog los tawm tsam kev hloov pauv huab cua.
Peb cov vaj huam sib luag yog tsim los ua kom muaj txiaj ntsig zoo tshaj plaws, siv cov thev naus laus zis tshiab los ntes lub hnub ci ntau li ntau tau thiab hloov mus rau hauv lub zog siv tau. Lawv kuj tau tsim kom kav ntev, nrog kev tsim kho rugged thiab cov ntaub ntawv zoo uas tuaj yeem tiv taus txawm tias qhov hnyav tshaj ib puag ncig.
Tsis tas li ntawd, peb cov panels yog ib qho yooj yim heev rau nruab thiab siv. Lawv yuav tsum tsis muaj cov cuab yeej tshwj xeeb lossis kev txawj ntse, thiab tuaj yeem teeb tsa hauv ib feeb xwb. Ib zaug nyob rau hauv qhov chaw, lawv yuav muab koj lub tsev lossis kev lag luam nrog lub zog huv, rov ua dua tshiab rau xyoo tom ntej.
Tab sis tej zaum qhov txiaj ntsig zoo tshaj plaws ntawm peb lub hnub ci vaj huam sib luag rau cov tuam txhab yog lawv cov kev cuam tshuam ib puag ncig. Los ntawm kev txo koj txoj kev cia siab rau cov khoom siv hluav taws xob ib txwm muaj, koj tab tom ua koj txoj haujlwm los tiv thaiv lub ntiaj teb thiab txo qhov cuam tshuam ntawm kev hloov pauv huab cua. Nrog peb cov vaj huam sib luag, koj tuaj yeem siv zog rau koj lub tsev lossis kev lag luam hauv txoj kev uas muaj kev ruaj khov thiab muaj lub luag haujlwm.
Freight thiab Them Nyiaj:
Peb zoo siab los muab peb cov neeg siv khoom ntau txoj hauv kev yooj yim them nyiaj, suav nrog credit cards, PayPal, hloov txhab nyiaj hauv tuam txhab, thiab nyiaj ntsuab ntawm tus me nyuam. Peb lub hom phiaj yog los xyuas kom meej tias txhua qhov kev lag luam yog seamless thiab tsis muaj kev ntxhov siab, yog li cov neeg siv khoom tuaj yeem tsom rau kev txaus siab rau peb cov khoom zoo thiab cov kev pabcuam zoo.
Hais txog kev xa khoom, peb siv zog los muab cov kev xaiv yooj yim thiab pheej yig kom tau raws li cov kev xav tau sib txawv. Peb tus qauv shipping txoj kev yog txhim khu kev qha thiab nqi-zoo, nrog kwv yees lub sij hawm xa khoom kom meej meej rau cov neeg muas zaub. Peb kuj muab kev xa khoom xa tuaj rau kev txiav txim ceev, nrog rau kev xa khoom dawb rau qee qhov kev txiav txim lossis kev txhawb nqa.
Thov nco ntsoov tias peb cov nqi thauj khoom yog nyob ntawm qhov hnyav thiab qhov chaw ntawm koj qhov kev txiav txim, thiab cov se lossis cov luag haujlwm yog lub luag haujlwm ntawm cov neeg siv khoom. Peb ntseeg hais tias nyob rau hauv pob tshab thiab ncaj ncees, thiab ib txwm tsom mus muab tus nqi zoo tshaj plaws rau peb cov neeg siv khoom.
Kev pabcuam neeg siv khoom:
1.Peb lub tuam txhab muaj ib pab neeg muab kev pab cuam uas muaj los pab koj nrog txhua yam kev nug lossis teeb meem koj muaj.
2.Peb tau cog lus los muab kev pabcuam sai thiab zoo rau peb cov neeg siv khoom, thiab siv zog los teb rau txhua qhov kev nug hauv 24 teev.
3.Peb tab tom saib xyuas cov neeg siv khoom tawm tswv yim los txhim kho peb cov khoom thiab cov kev pab cuam, thiab coj tag nrho cov lus qhia thiab cov lus pom zoo.
4.Our pab neeg muab kev pabcuam neeg siv khoom muaj los pab koj nrog cov lus nug, teeb meem, lossis kev txhawj xeeb uas koj muaj, thiab yuav ua haujlwm tsis tu ncua los daws txhua yam teeb meem.
5.Peb ntseeg tias txhua tus neeg siv khoom tseem ceeb thiab tsim nyog tau txais kev pabcuam zoo tshaj plaws, thiab yuav ua tib zoo saib xyuas koj, kev tshaj lij, thiab kev ua siab zoo.
Zoo heev mechanical load kuj
2400 Pa cua load, 5400 Pa daus load
Anti-PID (muaj peev xwm induced degradation)
Kev xeem dhau los tiv thaiv PID hauv qab 85% damp cua sov, 85% txheeb ze av noo rau 96 teev
Zoo Durability tiv thaiv huab cua
Dhau ntsev corrosion test, ammonia corrosion test, plua plav thiab xuab zeb kuaj, kuaj hluav taws, tag nrho cov ntawv pov thawj los ntawm TUV
Ob chav electroluminescence (EL) xeem
Ua tib zoo tshuaj xyuas ua ntej thiab tom qab lamination kom lav qhov tsis muaj qhov tsis raug
|
Monocrystalline hnub ci vaj huam sib luag 440W |
||||
|
Cov ntaub ntawv yooj yim |
||||
|
Qauv |
ED440W-36M |
|||
|
Qeb |
Monocrystalline solar vaj huam sib luag |
|||
|
Hluav taws xob ua haujlwm parameter |
||||
|
|
STC |
NOCT |
||
|
Lub zog siab tshaj plaws-Pmax |
Wp |
440 |
321 |
|
|
Lub zog kam rau ua |
% |
0-+5 |
0-+5 |
|
|
Lub zog siab tshaj plaws-Vmp |
V |
41.1 |
38.3 |
|
|
Kev ua haujlwm siab tshaj plaws tam sim no-Imp |
A |
10.71 |
8.6 |
|
|
Qhib Circuit Court voltage-Voc |
V |
48.9 |
45.8 |
|
|
Short-circuit tam sim no-Isc |
A |
11.46 |
9.27 |
|
|
Maximum System Voltage-VDC |
V |
1500 |
||
|
Txheem kuaj mob |
STC |
Irradiance 1000W / m2, ambient kub 25 degree, Atmospheric qualityAM1.5 |
||
|
Cheebtsam & Mechanical Data |
||||
|
Solar Cell (cov ntaub ntawv) |
Monocrystalline silicon |
|||
|
iav (khoom siv) |
Low-Iron tempered iav |
|||
|
Module ncej (khoom siv) |
Anodized aluminium alloy |
|||
|
Junction Box Hom (kev tiv thaiv degree) |
IP65 / IP67 |
|||
|
Cable (hli-sectional cheeb tsam / ntev) |
4mm ib2 90 cm + mc4 |
|||
|
Kub Coefficients |
||||
|
Ua haujlwm kub |
﹣ 40-+85 degree |
|||
|
Kub Coefficients ntawm Voc (%) degree |
-0.27% / degree |
|||
|
Kub Coefficient ntawm Pm (%) degree |
-0.35% / degree |
|||
|
Kub Coefficients ntawm Im (%) degree |
0.048% / degree |
|||
|
NOCT |
45 degree ± 2 degree |
|||
