Product Overview:
Edobo inverter hybrid ntawm daim phiaj 5kw yog ib tiam tshiab ntawm ib-theem zog cia inverter nrog kev ua tau zoo. Nws tuaj yeem hloov kho rau ntau yam kev siv hluav taws xob hauv tsev, suav nrog kev nkag mus rau tib lub sijhawm ntawm PV, roj teeb, thauj khoom, daim phiaj / diesel generator, built-in tus kheej tiam thiab kev siv tus kheej, ncov shaving thiab hav filling, roj teeb tseem ceeb, lub zog thaub qab, thiab lwm yam. hom kev ua haujlwm. Nws kuj txhawb nqa ntau chav nyob rau hauv parallel, AC ob peb, diesel generators, Anti-reflux, thiab lwm yam kev daws teeb meem.
Technical indexes:
|
ED3K-TL |
|
|
Cov tswv yim (DC) |
|
|
Max.Input zog |
4.5 kWm |
|
Max.Input voltage |
600V |
|
Pib Voltage |
80V |
|
Rated nyob rau hauv muab Voltage |
360V |
|
Puv-load MPP Voltage Range |
190V~480V |
|
MPPT Voltage Ntau |
80V~560V |
|
Tus naj npawb ntawm MPP Trackers |
1 |
|
Number of String ib MPPT |
1 |
|
Max.Current rau MPPT |
20A |
|
Max.Short Circuit Current per MPPT |
25A |
|
Cov zis (AC) |
|
|
Max.Output Tam sim no |
15A |
|
Rated tso zis zog |
3 kW |
|
Max.Output zog |
3.3kVA ua |
|
Rated Grid Frequency |
50Hz / 60Hz |
|
Rated Daim phiaj Voltage |
220VAC/230VAC/240VAC |
|
Hwj chim Factor |
>{{0}}.99 (0.8 ua ~ 0.8 lagging) |
|
TH Diam |
<3% (Rated Power) |
|
Kev ua tau zoo |
|
|
Max.Efficiency |
98.10% |
|
European Efficiency |
97.10% |
|
MPPT Efficiency |
99.90% |
|
Kev tiv thaiv |
|
|
DC rov qab polarity tiv thaiv |
Yog lawm |
|
Anti-islanding tiv thaiv |
Yog lawm |
|
AC luv Circuit Court tiv thaiv |
Yog lawm |
|
Residual tam sim no saib xyuas chav tsev |
Yog lawm |
|
Rwb thaiv tsev kuj saib xyuas |
Yog lawm |
|
Kev saib xyuas hauv av |
Yog lawm |
|
Daim phiaj saib xyuas |
Yog lawm |
|
PV txoj hlua saib xyuas |
Yog lawm |
|
Surge tiv thaiv |
Hom Ⅱ |
|
AFCI kev tiv thaiv |
Xaiv tau |
|
Kev sib txuas lus |
|
|
Zaub |
LED / LCD / WiFi + App |
|
Kev sib txuas lus |
RS485 / WiFi / 4G |
|
Txuj kev ua raws cai |
|
|
Grid Connection Standards |
IEC 61727, IEC 62116, IEC60068, VFE-AR-N 4110: 2018, VDE-AR-N4105: 2018 |
|
Kev nyab xeeb / EMC |
IEC 62109-1: 2010, IEC 62109-2: 2011, EN 61000-6-2: 2005, EN 61000-6-3: 2007/A1: 2011 |
|
Cov ntaub ntawv dav dav |
|
|
Qhov Loj (W * H * D) |
380 * 380 * 160 hli |
|
Qhov hnyav |
13kg ua |
|
Kev khiav hauj lwm qhov kub thiab txias |
-30 degree ~ +60 degree |
|
Txoj kev txias |
Ntuj |
|
Kev tiv thaiv qib |
IP66 |
|
Max.Operating Altitude |
4000m |
|
Reklative Humidity |
0~100% |
|
Topology |
Hloov tsis tau |
|
Hmo ntuj siv zog |
<1W |
Nta:
1. Hybrid Inverter: 5kW Inverter Hybrid On/Off Grid yog tsim los nrog hybrid technology, uas ua rau nws ua haujlwm rau ob qho tib si on-grid thiab off-grid hom. Nyob rau hauv cov ntaub ntawv ntawm daim phiaj tsis ua hauj lwm, lub inverter yuav cia li hloov mus rau off-grid hom, kom ntseeg tau tias tsis muaj kev cuam tshuam fais fab mov rau koj cov khoom siv yam tsis muaj kev cuam tshuam.
2. Sine Wave Output: Lub inverter muab cov zis ntshiab sine yoj tawm, ua rau nws tsim nyog rau cov khoom siv hluav taws xob, xws li TVs, tub yees, thiab khoos phis tawj.
3. High Power Output: Lub 5kW Inverter Hybrid On/Off Grid tuaj yeem xa mus txog 5000 watts ntawm lub zog, ua rau nws tsim nyog rau kev siv lub zog hnyav, xws li cua txias, thiab hluav taws xob cua sov.
4. Intelligent Battery Management System: Lub inverter yog smartly tsim nrog ib tug advanced roj teeb tswj system, uas ua kom pom kev siv roj teeb lub zog, ncua lub neej ntawm lub roj teeb.
5. User-Friendly Interface: Lub inverter los nrog tus neeg siv-phooj ywg interface thiab tus qauv tsim, ua rau nws yooj yim rau nruab thiab khiav lag luam.
6. Ib puag ncig-phooj ywg: 5kW Inverter Hybrid On/Off Grid yog ib qho khoom siv hauv ib puag ncig, ua kom muaj zog huv si yam tsis muaj cov pa phem, ua rau nws yog qhov kev xaiv zoo rau kev nyob ruaj khov.
Daim ntawv thov
5kW Inverter Hybrid On/Off Grid yog ntau yam khoom siv uas tuaj yeem siv rau ntau yam kev siv, xws li:
1. Chaw Nyob: Lub inverter yog ib qho kev xaiv zoo tshaj plaws rau cov tsev nyob, muab cov kev daws teeb meem txhim khu kev qha thaum lub hwj chim tawm.
2. Kev lag luam: Lub inverter yog ib qho kev xaiv zoo tshaj plaws rau kev lag luam, qhov twg cov cuab yeej tuaj yeem txhawb nqa kev hloov pauv ntawm lub zog loj.
3. Muaj: Lub inverter kuj tuaj yeem siv rau hauv kev lag luam, muab lub zog tsis cuam tshuam rau cov khoom siv tseem ceeb.
Xaus:
Lub 5kW Inverter Hybrid On/Off Grid yog qhov kev daws teeb meem zoo tshaj plaws rau cov neeg uas xav tau cov kev daws teeb meem muaj zog thiab muaj zog. Nws cov thev naus laus zis hybrid siab heev, tus neeg siv-phooj ywg interface, thiab kev tswj xyuas roj teeb ntse ua rau nws yog qhov kev xaiv zoo tshaj plaws rau tsev, chaw ua haujlwm, thiab kev lag luam.
