Hnub Ci Inverter 5kw
Hauj lwm lawm
Kev tsis
Product Overview:
Inverter Hnub Ci 5kW: Lub Caj Npab Ntawm Cov Hluav Taws Xob Hluav Taws Xob Hluav Taws Xob
Yog tias koj tab tom npaj hloov mus rau hnub ci zog, koj xav tau lub zog thiab txhim khu kev qha inverter. Inverters yog lub caj qaum ntawm txhua lub hnub ci zog, hloov DC tsim los ntawm hnub ci vaj huam sib luag rau hauv AC hluav taws xob siv tau los ntawm koj lub tsev. Inverter Hnub Ci 5kW yog ib qho ntawm cov kev xaiv nrov tshaj plaws muaj nyob rau hauv kev ua lag luam vim nws haum rau cov haujlwm me me thiab nruab nrab.
Inverter Solar 5kW yog dab tsi?
Inverter Hnub Ci 5kW yog ib hom hlua inverter uas yog tsim los tswj cov zis ntawm lub hnub ci vaj huam sib luag nrog lub peev xwm siab tshaj plaws ntawm 5kW. Nws tseem tau nruab nrog cov yam ntxwv zoo li qhov siab tshaj plaws lub zog taw tes nrhiav (MPPT) thev naus laus zis uas pab txhawm rau rho tawm qhov siab tshaj plaws ntawm lub zog ntawm lub hnub ci vaj huam sib luag thiab muab cov txiaj ntsig zoo tshaj plaws rau daim phiaj hluav taws xob. Lwm feature ntawm Inverter Hnub Ci 5kW yog nws cov neeg siv-phooj ywg LCD zaub uas qhia cov ntaub ntawv tseem ceeb xws li DC voltage, AC voltage, thiab lub zog tso zis.
Cov yam ntxwv tseem ceeb:
Qhov zoo ntawm Inverter Hnub Ci 5kW
Ua ntej txiav txim siab xaiv Inverter Hnub Ci 5kW, nws yog ib qho tseem ceeb kom nkag siab txog qee qhov zoo nws muab:
1. Compact thiab ruaj khov: Inverter Hnub Ci 5kW yog tsim los ua lub teeb yuag thiab compact, ua rau nws yooj yim rau nruab thiab txav mus los yog xav tau. Ntxiv mus, nws yog tsim los siv cov ntaub ntawv zoo uas tuaj yeem tiv taus huab cua hnyav.
2. Kev ua tau zoo ntxiv: Nrog cov cuab yeej MPPT siab heev, Inverter Hnub Ci 5kW rho tawm qhov siab tshaj plaws ntawm lub hnub ci zog thiab xa mus rau hauv daim phiaj hluav taws xob, yog li ua rau koj lub hnub ci zog ntau dua.
3. Yooj yim rau siv: Lub LCD zaub ntawm Inverter Hnub Ci 5kW muab tag nrho cov ntaub ntawv tseem ceeb txog lub zog tso zis, uas ua rau nws yooj yim rau cov neeg siv saib xyuas thiab tswj lawv lub hnub ci zog.
4. Nqis: Inverter Hnub Ci 5kW yog ib qho ntawm cov kev xaiv pheej yig tshaj plaws nyob rau hauv kev ua lag luam, ua rau nws yog ib qho kev xaiv zoo rau cov neeg uas tab tom nrhiav kev daws teeb meem nyiaj txiag rau hnub ci zog.
Xaus
Inverter Hnub Ci 5kW yog ib qho tseem ceeb ntawm txhua lub hnub ci zog uas muab kev ntseeg tau thiab ua haujlwm tau zoo. Nrog nws cov yam ntxwv siab heev thiab pheej yig, nws tau dhau los ua kev xaiv nrov ntawm cov tswv tsev uas tab tom nrhiav hloov mus rau hnub ci zog. Yog li, yog tias koj tab tom xav txog hnub ci zog rau koj lub tsev, nco ntsoov xaiv Inverter Hnub Ci 5kW rau kev paub txog hnub ci zog.
Daim duab thov:
Technical indexes:
|
Qauv: ED-NKM- |
0 3-1KW |
1. 5-6KW |
|||
|
lub zog ntsuas (w) |
300 |
700 |
1500 |
3000 |
5000 |
|
500 |
1000 |
2000 |
4000 |
6000 |
|
|
Roj teeb |
|||||
|
Rated voltage (VDC) |
12/24 |
12/24/48 |
24/48 |
48 |
|
|
Charge tam sim no |
10 A MAX |
30 A MAX |
|||
|
Hom roj teeb |
Yuav tau teem |
||||
|
Tswv yim |
|||||
|
Voltage Ntau |
85-138VAC/170-275VAC |
||||
|
zaus |
45-65Hz |
||||
|
Tso zis |
|||||
|
Voltage Ntau |
110VAC / 220VAC; ± 5% (Inverter hom) |
||||
|
zaus |
50/60Hz ± 1% (Inverter hom) |
||||
|
Tso zis nthwv dej |
Pure Sine Wave |
||||
|
Hloov sijhawm |
<10ms(Typical load) |
||||
|
zaus |
>85% (80% Resistive load) |
||||
|
overcharge |
110-120%/30S;>160% / 300ms; |
||||
|
Kev tiv thaiv muaj nuj nqi |
Roj teeb tshaj-voltage thiab low-voltage tiv thaiv, overload tiv thaiv, luv luv tiv thaiv, tiv thaiv dhau-kub |
||||
|
Solar Controller |
|||||
|
MPPT Voltage Ntau |
12VDC: 15V ~ 150VDC; 24VDC: 30V ~ 150VDC; 48VDC: 60V ~ 150VDC |
||||
|
PV zog |
12VDC-30A(400W); 24VDC-30A (800W |
12VDC-60A(800W); |
|||
|
24VDC-60A(1600W); |
|||||
|
48VDC -60A (3200W) |
|||||
|
Rated nqi tam sim no |
30A (Max) |
60A (Max) |
|||
|
MPPT efficiency |
Ntau dua lossis sib npaug li 99% |
||||
|
Nruab nrab them voltage (lead acid roj teeb) |
12V / 14.2VDC; 24V / 28.4VDC; 48V / 56.8VDC |
||||
|
Floating charge voltage |
12V / 13.75VDC; 24V / 27.5VDC; 48V / 55VDC |
||||
|
Ua haujlwm kub ambient |
-15-+50 degree |
||||
|
Cia ambient kub |
-20 -+50 degree |
||||
|
Kev khiav hauj lwm / khaws cia ib puag ncig |
0-90% Tsis muaj condensation |
||||
|
Qhov Loj: W * D * H (mm) |
420*320*122 |
520*420*222 |
|||
|
Ntim qhov loj: W * D * H (mm) |
535*435*172 |
635*535*252 |
|||
